DESCRIPTION
1. Temperature Of Drying Chamber: -40。C~+50。C.
2. Temperature Of Water Collector: -50。C~-60。C.
3. Use Two-Stage Semi-Hermetic Compressor With CFC FREE Refrigerants R507.
4. Chamber Is Made By SUS304 With 10mm Thickness Of Mirror Polished.
5. Pre-Freezing System uses conducting silicone fluid cooling system.
6. Use Dry Screw Vacuum Pump / Cooling Is by Cooling Tower.
7. Use 1 Set 16 Steps / 2 Sets 8 Steps Micro-Computer Temperature Control System.
8. With 16 Sets Of Temperature Sensor On Each Tray.
9. With 96 Pieces Of Drying Trays For Approx. 300-400L Raw Material.
(TA-100L Has 32 Trays for approx. 100-130L Raw Material.)
SPECIFICATION
1. Dimension: Approx. L 6,080mm x W 2,150mm x H 2,450mm
2. Weight: 12,000kg / Max Power Consumption: 75kW
